Winch/servo Rescue Truck Tow Truck Crane Arm Wrecker For 1/10 Scx10 Trx4 Rc Car

Serves/Winch Double Stent Rescue Truck/Tow Truck Crane Arm Wrecker Kit for 1/0 RC Crawler SCX10 TRX4 Capra LCG Chassis Tools
Description: 1.CNC aluminum alloy,anodized 2.Upgrade the self assembling chassis rails and replace the performance climbing car's rear tailboard (suitable for rails with flat tail structure) 3.Enhance aesthetics and visual appeal 4.Winch and servo dual brackets can provide dual power(1/10 electric winch and 360° winch steering gear) 5.Reserve multiple support fixing holes, with adjustable installation inclination and height, suitable for installation at the tail of various chassis rails, solving the compatibility problem of single tail plate cargo warehouse 6.The installation size is 67mm wide, and other chassis with a width of 70mm/75mm/78mm can be equipped with washers and long screws for use 7.Can use our store's winch/winch servo/lifting rope/hook/lead combination
Notice: Winch upgrades are mainly for decorative purposes and are shipped unassembled, only including rescue towing hook bracket sets (winch/winch servo/lifting rope/hook/lead ball head not included)
Specifications: Material: Aluminum alloy (main frame), stainless steel (fixed pulley/silver screw), copper (sleeve) Size: 135 * 67 * 112mm (lowest installation position) (adjustable installation angle/height) Color: Black, Silver Weight: 104g   Product name: 35KG Servo Materials: plastic, aluminum alloy, alloy steel, electronic components Motor: Core Motor Output teeth: 25T Voltage range: 4.8V-8.4V 800-2200us angle: 360 ° Size: 40 * 20.2 * 41mm (excluding installation side ears and top shaft teeth) Servo line: JR, 300mm Weight: 65g Waterproof performance: IP66 (dustproof and splash proof) Stop rotating: 1430us-1530us From slow to fast/counterclockwise: 1530us-2200us From slow to fast/clockwise: 800us-1430us Installation wiring/control method: The third channel of the receiver is powered on, and the third channel switch of the remote control controls the forward and reverse continuous rotation Product name: Winch Wheel Materials: Aluminium Standard Winch Spool Teeth:25T Steel Rope Length: 180cm Wheel size: 20*16mm Weight: 12g Product name:Winch tow rope/Trailer Hook Material: Polyethylene fiber/Metal Color: Red, Blue Diameter: 1mm Length: 2m(78.74in)
Note: Winch is not included in Tow Truck kit, only including rescue towing hook bracketsets (winch/winch servo/liftina rope/hook/lead ball head not included)If you need a complete installation, you need to purchase the required accessories according to the link options.
